High Bay LED Light 2Ft. 120W 16120 Lumens 5000K UL DLC

Rating:
100 % of 100

Availability: In stock

SKU
N2W-EWF-1B16J-50
Certification LogoCertification LogoCertification LogoCertification LogoCertification LogoCertification Logo
120 Watt 2Ft. linear LED high bay light with 16120 lumens output. Frosted lens to reduce glare and spread the light evenly that do not reflect the LED dots in the areas being illuminated. Perfect for showrooms with ceilings up to 24Ft high. Mounting these fixtures aligned with the shelves is more efficient than round fixtures that waste a big portion of the light shining at the top of the shelves. Especially designed for warehouses and large big box retail stores, indoor courts, etc.. This fixture can be made dimmable to 10% with appropriate LED 0-10 VDC dimmer. Comes with V-hook clips, chains and frosted lens. Good for mounting height from 16 ft to 24 feet from the floor. Easy to install and clean. Click here to see other Linear High Bay Lights.
Special Price $82.85 Regular Price $97.00
  • Buy 10 for $78.71 each and save 5%
  • Buy 25 for $76.22 each and save 8%
  • Buy 50 for $74.56 each and save 10%
  • Buy 100 for $72.91 each and save 12%
SPECIFICATIONS:
SKU: N2W-EWF-1B16J-50
Certification LogoCertification LogoCertification LogoCertification LogoCertification LogoCertification Logo
Replaces up to 5 T5 HO!
Electrical:
Watts:120
Operating Voltage:100-277 VAC
Operating Temperature:-22° F to 122° F
Operating Humidity:20% to 90%RH
Power Factor (PF):>98%
Power Supply Efficiency:>96%
Photometric:
LED Luminous Flux (lm):16120
Luminous Efficiency: 134
CRI (ra):>80
Color Temperature (Kelvin):5000 K
Lens type:Frosted
Expected Life:70,000 hrs.
L70:50,000 hrs.
Beam Angle:120º
Mechanical:
IP Rating:IP40
Connector:Wired
Base Type:Hardwired
Heat Radiator:Anodized Aluminum
Color:White
Product Size:24X12.6"X3.74"
Package Size: 26'' x 14'' x 7''
Package Weight:9.900000 Lb
Certifications:
Safety Compliance:
Energy Efficiency/Performance:
APPLICATIONS:
And more

High Bay LED lights are essential for commercial settings such as warehouses, factories, and large retail stores. They provide powerful illumination, increase energy efficiency, and save money on electricity bills. One of the most popular options in the market is the 2ft 120W High Bay LED light that delivers a whopping 16120 lumens of brightness and operates at a color temperature of 5000K. This lighting fixture is UL and DLC certified, ensuring its durability, efficiency, and safety.

The 2ft High Bay LED light is designed to provide maximum illumination in large spaces. Its high lumen output makes it perfect for high-ceiling areas, where it can effectively replace traditional high-pressure sodium, metal halide, or fluorescent lights. With a beam angle of 120 degrees, it can cover a wide area with minimal glare, creating a bright, even, and comfortable working environment.

One of the significant advantages of using the 2ft High Bay LED light is its energy efficiency. Compared to traditional lighting fixtures, LED lights consume significantly less power, leading to reduced energy bills and carbon emissions. Moreover, LED lights have a longer lifespan and require minimal maintenance, reducing the need for frequent replacements and repairs.

The 2ft High Bay LED light is also versatile and can be used in various commercial settings. Whether you need to illuminate a large warehouse, a manufacturing facility, a gymnasium, or a retail store, this lighting fixture can provide the necessary brightness and clarity to enhance visibility and safety. Its durable construction, coupled with its resistance to shock, vibration, and extreme temperatures, make it an ideal choice for harsh environments.

Another advantage of the 2ft High Bay LED light is its ease of installation. It comes with mounting hardware and accessories, making it easy to install on the ceiling or suspend from chains or cables. Additionally, LED lights do not require any warm-up time and can be turned on instantly, providing instant brightness and reducing downtime.

In summary, the 2ft 120W High Bay LED light is a reliable, energy-efficient, and versatile lighting solution for commercial settings. Its high lumen output, 5000K color temperature, and 120-degree beam angle make it suitable for large spaces, while its UL and DLC certification ensures its safety and durability. Whether you need to illuminate a warehouse, factory, gym, or store, this lighting fixture can provide the necessary illumination to enhance productivity, safety, and customer experience.

More Information
DLC_QPL PAMHQD1Y
Additional Information
LED HIGH BAY INSTALLATION GUIDE
(Follow these instructions for 2Ft. and 4Ft. linear high bays)

PLEASE READ ALL INSTRUCTIONS BEFORE STARTING INSTALLATION

- To prevent personal injury or product damage only licensed electricians should install.
- To avoid electric shock or component damage disconnect power before attempting installation or servicing.
- This product must be installed in accordance with the national electric code (NEC) and all applicable federal, state and local electric codes and safety standards.
- Disconnect product and allow cooling prior to servicing.
- Any alteration or modification of this product is expressly dicouraged as it may cause serious personal injury, death, property damage and/or product malfunction and will void the warranty.
- To prevent product malfunction and/or electrical shock this product must be properly grounded.
- This luminaire is designed to operate at room temperatures ranging from -22F to 104F and to be horizontally mounted with the LEDs facing down.


Installation


1. Using provided steel wire and the High Bay top as J-box



Save the environment, your children and the planet
615 N 21st Ave., Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com www.ledradiant.com

5 YEAR WARRANTY POLICY
For Commercial LED Lamps and fixtures


This document sets forth the warranty policy of the LEDRadiant organization (‘LEDRadiant’) from which you (‘Purchaser’) purchase your commercial LED Lamps .

This policy is applicable only to LEDRadiant (‘Products’) described in the Warranty Certificate extended to the Purchaser along with the correlated invoice or the Certificate in the website page for the product being questioned.

This warranty policy is subject to the provisions as set forth herein and is subject to the terms and conditions as attached to this document (‘Warranty Terms and Conditions’) .

This warranty policy only applies if referred to in a sales agreement between LEDRadiant and the Purchaser and it will replace the standard warranty clause provided in the LEDRadiant general terms and conditions of sale.

Warranty period
5 Year. The warranty period starts on the date the products are delivered.
By default, purchaser receives above mentioned ‘standard warranty’.

On request, an ‘extended warranty’ or ‘customized project warranty’ can be agreed upon after evaluation of the specific application conditions. Extended warranty cost will be calculated and applied to the order.

Purchaser shall not rely upon any other information or documentation.

Within the warranty period, LEDRadiant will replace any defective bulb or fixture with equal or updated working model in the same conditions or better.

Summary Warranty Terms and Conditions (non-exhaustive)

This warranty policy is valid only for products sold in The United States of America.
Products have been purchased directly from a LEDRadiant (sales) organization.
Proof of purchase is available for inspection by LEDRadiant.
Products have been properly installed and operated in accordance with the manufacturer’s instructions.
• More than 10% of the LED chips are not properly working.
A LEDRadiant representative will have access to the defective Products.
If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems.
Shipping and Labor costs for installation of the Products are not covered under this warranty.

This warranty is valid for order number:




By LEDRadiant

Save the environment, your children and the planet
615 N 21st Ave., Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com www.ledradiant.com
