LED Panel Light 2x2 3250 3900 4680 Lm Back lit 3500K 4000K 5000K UL/DLC

Be the first to review this product

Availability: In stock

SKU

P2E-SBF-X0520-SW

LED panel lights back lit, dimmable, selectable power and Color Temperature. Replacing fluorescent with this LED flat panel lights is economical, simple and practical as these panels can be set for 30W, 35W and 40W, 3500K, 4000K and 5000K and are dimmable. Lifespan is over 25 years if used 12 hours a day. The panel can be installed easily in very shallow ceilings. High-powered white LEDs provide high CRI and energy efficient lighting. Estimated annual ROI is about 50%.

Special Price $57.85 Regular Price $68.00

Buy 10 for $54.96 each and save 5%
Buy 25 for $53.22 each and save 8%
Buy 50 for $52.07 each and save 10%
Buy 100 for $50.91 each and save 12%

Product Description

Additional Information

Reviews

Product Tags

FAQ

LED Replacement for 2 x 2 Troffer

Electrical:

 Watts:40
 Operating Voltage:100-277 VAC
 Operating Temperature:-22° F to 122° F
 Operating Humidity:20% to 90%RH
 Power Factor (PF):>98%
 Power Supply Efficiency:>90%

Photometric:

 LED Luminous Flux (lm):4680
 Luminous Efficiency:  117
 CRI (ra):>70
 Color Temperature (Kelvin):Tunable 3.5/4/5K
 Lens type:Frosted
 Expected Life:70,000 hrs.
 L70:50,000 hrs.
 Beam Angle:150º

Mechanical:

 IP Rating:IP40
 Connector:Driver
 Base Type:Hardwired
 Heat Radiator:Anodized Aluminum
 Color:Off White
 Product Size:24" x 24"
  Package Size: 25'' x 25'' x 2.5''
 Package Weight:8.000000 Lb

Certifications:

 Safety Compliance:
 EMI/RFI compliance:FCC
 Energy Efficiency/Performance:
 Environmental:RhOS

APPLICATIONS:

And more

More Information
Additional Information	click here to download the PDF file. 5 YEAR WARRANTY POLICY For Commercial LED Lamps and fixtures This document sets forth the warranty policy of the LEDRadiant organization (‘LEDRadiant’) from which you (‘Purchaser’) purchase your commercial LED Lamps . This policy is applicable only to LEDRadiant (‘Products’) described in the Warranty Certificate extended to the Purchaser along with the correlated invoice or the Certificate in the website page for the product being questioned. This warranty policy is subject to the provisions as set forth herein and is subject to the terms and conditions as attached to this document (‘Warranty Terms and Conditions’) . This warranty policy only applies if referred to in a sales agreement between LEDRadiant and the Purchaser and it will replace the standard warranty clause provided in the LEDRadiant general terms and conditions of sale. Warranty period 5 Year. The warranty period starts on the date the products are delivered. By default, purchaser receives above mentioned ‘standard warranty’. On request, an ‘extended warranty’ or ‘customized project warranty’ can be agreed upon after evaluation of the specific application conditions. Extended warranty cost will be calculated and applied to the order. Purchaser shall not rely upon any other information or documentation. Within the warranty period, LEDRadiant will replace any defective bulb or fixture with equal or updated working model in the same conditions or better. Summary Warranty Terms and Conditions (non-exhaustive) • This warranty policy is valid only for products sold in The United States of America. • Products have been purchased directly from a LEDRadiant (sales) organization. • Proof of purchase is available for inspection by LEDRadiant. • Products have been properly installed and operated in accordance with the manufacturer’s instructions. • More than 10% of the LED chips are not properly working. • A LEDRadiant representative will have access to the defective Products. • If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems. • Shipping and Labor costs for installation of the Products are not covered under this warranty. This warranty is valid for order number: By LEDRadiant Save the environment, your children and the planet 500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230 Contact@ledradiant.com – www.ledradiant.com
