LED Downlight 10 inch 22W/28W/33W 3300Lm 30K/40K/50K 0-10V Dimmable

Availability: In stock

SKU
DNF-JTF-33330-SW
Certification LogoCertification LogoCertification LogoCertification LogoCertification Logo

These10inch commercial LED Downlights are brighness and CCT tunable.

Upgrade your lighting with our LED Downlight 10 inch! Our downlight is selectable in three wattage options (22W/28W/33W) and three color temperatures (30K/40K/50K) to suit your needs. With a brightness of 3300Lm, our downlight is perfect for illuminating any space. Plus, it's dimmable with a 0-10V dimmer switch for added convenience. Our LED Downlight 10 inch is energy-efficient and long-lasting, making it a great choice for your home or office. Order now and experience the difference!

Click here to see other Downlights.

Special Price $74.25 Regular Price $87.00
  • Buy 10 for $70.54 each and save 5%
  • Buy 25 for $68.31 each and save 8%
  • Buy 50 for $66.83 each and save 10%
  • Buy 100 for $65.34 each and save 12%
SPECIFICATIONS:
SKU: DNF-JTF-33330-SW
Certification LogoCertification LogoCertification LogoCertification LogoCertification Logo
LED Dimable 0-10V for recessed fixture 10" up to 175W HID.
Electrical:
Watts:33
Operating Voltage:120-277 VAC
Operating Temperature:-22° F to 104° F
Operating Humidity:20% to 90%RH
Power Factor (PF):>90%
Power Supply Efficiency:>98%
Photometric:
LED Luminous Flux (lm):3300
Luminous Efficiency: 100
CRI (ra):>80
Color Temperature (Kelvin):Tunable 3/4/5K
Lens type:Frosted
Expected Life:70,000 hrs.
L70:50,000 hrs.
Beam Angle:105º
Mechanical:
IP Rating:IP54
Connector:Wired
Base Type:Hardwired
Heat Radiator:Anodized Aluminum
Color:Off White
Product Size:Ø8.31" x 4.38"
Package Size: 12'' x 12'' x 5''
Package Weight:1.500000 Lb
Certifications:
Safety Compliance:
Energy Efficiency/Performance:
APPLICATIONS:
And more

LED downlights have become increasingly popular in recent years, and for good reason. These energy-efficient lighting fixtures are designed to provide excellent illumination while consuming minimal power. Among the many types of LED downlights available in the market, the 10-inch LED downlight is one of the most versatile and powerful options.

This LED downlight has a wattage range of 22W, 28W, or 33W, providing ample lighting for different room sizes and lighting needs. Additionally, it boasts a high lumen output of 3300Lm, making it perfect for commercial, residential, and industrial lighting applications. Moreover, it has a 0-10V dimmable feature, allowing users to adjust the light intensity to their desired levels.

The LED downlight is also selectable in terms of both wattage and CCT (Correlated Color Temperature). This means that you can customize the wattage and CCT to suit your specific lighting needs. The CCT range includes 30K, 40K, or 50K, providing options for warm, neutral, or cool lighting.

The 10-inch LED downlight is an excellent replacement for traditional halogen or incandescent bulbs. It consumes less energy and lasts longer, reducing maintenance costs and electricity bills. Additionally, LED lights emit less heat, making them safer and more comfortable to use.

One of the standout features of this LED downlight is its 0-10V dimming capability. This allows for greater flexibility in lighting design, enabling users to create different lighting scenes and moods. The dimming feature also contributes to energy savings, as you can adjust the light levels based on occupancy or daylight availability.

The selectable wattage and CCT features also make this LED downlight a popular choice for a wide range of lighting applications. It is commonly used in commercial settings such as retail stores, hotels, and offices, as well as in residential settings such as living rooms, dining rooms, and kitchens. Its versatility and adaptability make it a great investment for any lighting project.

In conclusion, the 10-inch LED downlight is a high-quality, energy-efficient lighting solution that provides excellent illumination with minimal power consumption. Its 0-10V dimming feature, selectable wattage and CCT, and high lumen output make it an excellent choice for a wide range of lighting applications. Investing in this LED downlight can save you money on electricity bills while providing long-lasting, reliable lighting.

More Information
Additional Information
5 YEAR WARRANTY POLICY
For Commercial LED Lamps and fixtures


This document sets forth the warranty policy of the LEDRadiant organization (‘LEDRadiant’) from which you (‘Purchaser’) purchase your commercial LED Lamps .

This policy is applicable only to LEDRadiant (‘Products’) described in the Warranty Certificate extended to the Purchaser along with the correlated invoice or the Certificate in the website page for the product being questioned.

This warranty policy is subject to the provisions as set forth herein and is subject to the terms and conditions as attached to this document (‘Warranty Terms and Conditions’) .

This warranty policy only applies if referred to in a sales agreement between LEDRadiant and the Purchaser and it will replace the standard warranty clause provided in the LEDRadiant general terms and conditions of sale.

Warranty period
5 Year. The warranty period starts on the date the products are delivered.
By default, purchaser receives above mentioned ‘standard warranty’.

On request, an ‘extended warranty’ or ‘customized project warranty’ can be agreed upon after evaluation of the specific application conditions. Extended warranty cost will be calculated and applied to the order.

Purchaser shall not rely upon any other information or documentation.

Within the warranty period, LEDRadiant will replace any defective bulb or fixture with equal or updated working model in the same conditions or better.

Summary Warranty Terms and Conditions (non-exhaustive)

This warranty policy is valid only for products sold in The United States of America.
Products have been purchased directly from a LEDRadiant (sales) organization.
Proof of purchase is available for inspection by LEDRadiant.
Products have been properly installed and operated in accordance with the manufacturer’s instructions.
• More than 10% of the LED chips are not properly working.
A LEDRadiant representative will have access to the defective Products.
If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems.
Shipping and Labor costs for installation of the Products are not covered under this warranty.

This warranty is valid for order number:




By LEDRadiant
