LED Garage Lights | 27W 3800Lm 5000K

Rating:
100 % of 100

Availability: In stock

SKU
CCM-SBS-27380-50
Certification LogoCertification LogoCertification LogoCertification LogoCertification Logo

This LED 27 watt canopy light replaces up to 175 Watt HID, save up to 75% in electricity and hundreds in unnecessary garage light fixture replacements. Typical annual ROI > 40%. LEDRADIANT canopy lights are easy to install, are IP65 waterproof, apt to be used outdoors, in wet locations. Ul and DLC listed.

For more Garage Canopy Lights.

Special Price $51.55 Regular Price $61.00
  • Buy 10 for $48.97 each and save 5%
  • Buy 25 for $47.43 each and save 8%
  • Buy 50 for $46.40 each and save 10%
  • Buy 100 for $45.36 each and save 12%
SPECIFICATIONS:
SKU: CCM-SBS-27380-50
Certification LogoCertification LogoCertification LogoCertification LogoCertification Logo
LED Replacement for up to 175 Watt HID
Electrical:
Watts:27
Operating Voltage:90-277 VAC
Operating Temperature:-22° F to 122° F
Operating Humidity:10% to 100%RH
Power Factor (PF):>95%
Power Supply Efficiency:>90%
Photometric:
LED Luminous Flux (lm):3800
Luminous Efficiency: 141
CRI (ra):>75
Color Temperature (Kelvin):5000 K
Lens type:Prismatic
Expected Life:70,000 hrs.
L70:50,000 hrs.
Beam Angle:160º
Mechanical:
IP Rating:IP65
Connector:Wired
Base Type:Hardwired
Heat Radiator:Anodized Aluminum
Color:Brown (dark)
Product Size: 9.57\'\'x9.57\'\'x2.87\'\'
Package Size: 11'' x 12'' x 5''
Package Weight:6.200000 Lb
Certifications:
Safety Compliance:
Energy Efficiency/Performance:
APPLICATIONS:
And more

When it comes to illuminating a garage or workshop, finding the right lighting solution can make all the difference. LED garage lights have become increasingly popular in recent years due to their energy efficiency, long lifespan, and bright illumination. One popular option in the market is the 27W 3800Lm 5000K LED garage light, which is designed to provide bright and clear illumination to help you work more efficiently and safely.

The 27W LED garage light is a high-performance lighting solution that is perfect for both residential and commercial use. It produces a bright and clear light with a color temperature of 5000K, which is ideal for tasks that require good visibility and color accuracy. With a luminous flux of 3800 lumens, this light can easily illuminate large spaces, such as garages, workshops, or storage areas.

One of the primary benefits of LED garage lights is their energy efficiency. Unlike traditional lighting solutions, LED lights consume less energy while still providing the same or even higher levels of illumination. The 27W LED garage light is no exception, as it can provide bright and clear illumination while using only a fraction of the energy that traditional lights use. This can help you save money on your energy bills while also reducing your carbon footprint.

In addition to their energy efficiency, LED garage lights also have a much longer lifespan than traditional lighting solutions. The 27W LED garage light can last up to 50,000 hours, which means that you won't have to replace it as often as traditional lights. This can help you save money on maintenance costs over time, as well as reduce the amount of waste that ends up in landfills.

The 27W LED garage light is also very easy to install, with a simple plug-and-play design that requires no special tools or skills. You can easily replace your existing lighting fixtures with these LED lights and start enjoying their benefits right away. Plus, the lights are very durable and built to last, with a sturdy aluminum housing and a shatterproof polycarbonate lens that can withstand harsh conditions.

Finally, the 27W LED garage light is also very versatile and can be used for a wide range of applications. Whether you need to illuminate a large workshop or a small garage, these lights can provide the brightness and clarity that you need. They can also be used in outdoor settings, such as parking lots or outdoor storage areas, thanks to their durable and weather-resistant design.

In summary, the 27W 3800Lm 5000K LED garage light is an excellent lighting solution for both residential and commercial use. It provides bright and clear illumination while consuming less energy and lasting longer than traditional lights. Its easy installation, durability, and versatility make it a popular choice for anyone who needs reliable and efficient lighting for their garage or workshop.

More Information
DLC_QPL P6384V2E
Additional Information
CANOPY INSTALLATION GUIDE
(CCM-SBS-45410-40&50- CCM-SBS-70590-40&50)

PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION

- To prevent personal injury or product damage only licensed electricians should install.
- To avoid electric shock or component damage disconnect power before attempting installation or servicing.
- This product must be installed in accordance with the national electric code (NEG) and all applicable federal, state and local electric codes and safety standards.
- Disconnect product and allow cooling prior to servicing.
- Any alteration or modification of this product is expressly forbidden as it may cause serious personal injury, death, property damage and/or product malfunction.
- To prevent product malfunction and/or electrical shock this product must be properly grounded.
- This luminaire is designed to operate in ambient temperatures ranging from -25•C to 40•C and to be horizontally mounted with the LEOs facing down.


Installation


1. Surface Mounted with J-box


1. Loosen the screw on side of the light, removing the bracket from canopy light by pulling it out slightly, just leaving the ring on bracket.

2. Fix the bracket on J-box, and put the wire through the central hole for wiring


3. Attach the Canopy light with bracket by putting the ring on clips again. Connect the black wire for Line, white for Neutral and Yellow-Green for Ground.
4. Slide the Canopy lights into bracket, and secure the screw on side of the light to prevent the light from sliding out from the bracket. Installation done.

2. Pendent with 3/4 inch Conduit


1. Loosen the screw on side of the light, removing the bracket from Canopy light by pulling it slightly out, just leaving the ring on bracket. (See the Step 1 above)
2. Connect the wires threaded from conduit and Canopy, Black wire for Line, White for Neutral and Yellow-Green for Ground.

3. Screw the Conduit the hole on top of Canopy light





3. Surface Mount


1. Remove the lens and metal plate by unscrewing the screws.





2. Cut off the wires through from 3/4" hole and 3. Remove 1/2" plug from direction intent to feed conduit.




3. Drill 4 holes on edge of fixture and fix it on the ceiling with using appropriate screws.




4. Disconnect the wires came from 3/4" hole and connect the wires came from 1/2" conduit with power supply (White for Neutral Black for Line and Yellow Green-Green for Ground)

5. Replace the metal plate and the lens, make sure no wires are pinched when replacing parts.

Save the environment, your children and the planet
500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com www.ledradiant.com
5 YEAR WARRANTY POLICY
For Commercial LED Lamps and fixtures


This document sets forth the warranty policy of the LEDRadiant organization (‘LEDRadiant’) from which you (‘Purchaser’) purchase your commercial LED Lamps .

This policy is applicable only to LEDRadiant (‘Products’) described in the Warranty Certificate extended to the Purchaser along with the correlated invoice or the Certificate in the website page for the product being questioned.

This warranty policy is subject to the provisions as set forth herein and is subject to the terms and conditions as attached to this document (‘Warranty Terms and Conditions’) .

This warranty policy only applies if referred to in a sales agreement between LEDRadiant and the Purchaser and it will replace the standard warranty clause provided in the LEDRadiant general terms and conditions of sale.

Warranty period
5 Year. The warranty period starts on the date the products are delivered.
By default, purchaser receives above mentioned ‘standard warranty’.

On request, an ‘extended warranty’ or ‘customized project warranty’ can be agreed upon after evaluation of the specific application conditions. Extended warranty cost will be calculated and applied to the order.

Purchaser shall not rely upon any other information or documentation.

Within the warranty period, LEDRadiant will replace any defective bulb or fixture with equal or updated working model in the same conditions or better.

Summary Warranty Terms and Conditions (non-exhaustive)

This warranty policy is valid only for products sold in The United States of America.
Products have been purchased directly from a LEDRadiant (sales) organization.
Proof of purchase is available for inspection by LEDRadiant.
Products have been properly installed and operated in accordance with the manufacturer’s instructions.
• More than 10% of the LED chips are not properly working.
A LEDRadiant representative will have access to the defective Products.
If the Products or other parts become suspect, the representative shall have the right to invite other manufacturers’ representatives to evaluate the lighting systems.
Shipping and Labor costs for installation of the Products are not covered under this warranty.

This warranty is valid for order number:




By LEDRadiant

Save the environment, your children and the planet
500 North Dixie Hwy, #8, Hollywood, FL 33020 – (844).533.7230
Contact@ledradiant.com www.ledradiant.com
