Product Description

SPECIFICATIONS:
SKU: DNF-JTF-33330-SW
Certification LogoCertification LogoCertification LogoCertification LogoCertification Logo
LED Dimable 0-10V for recessed fixture 10" up to 175W HID.
Electrical:
Watts:33
Operating Voltage:120-277 VAC
Operating Temperature:-22° F to 104° F
Operating Humidity:20% to 90%RH
Power Factor (PF):>90%
Power Supply Efficiency:>98%
Photometric:
LED Luminous Flux (lm):3300
Luminous Efficiency: 100
CRI (ra):>80
Color Temperature (Kelvin):Tunable 3/4/5K
Lens type:Frosted
Expected Life:70,000 hrs.
L70:50,000 hrs.
Beam Angle:105º
Mechanical:
IP Rating:IP54
Connector:Wired
Base Type:Hardwired
Heat Radiator:Anodized Aluminum
Color:Off White
Product Size:Ø8.31" x 4.38"
Package Size: 12'' x 12'' x 5''
Package Weight:1.500000 Lb
Certifications:
Safety Compliance:
Energy Efficiency/Performance:
APPLICATIONS:
And more

LED downlights have become increasingly popular in recent years, and for good reason. These energy-efficient lighting fixtures are designed to provide excellent illumination while consuming minimal power. Among the many types of LED downlights available in the market, the 10-inch LED downlight is one of the most versatile and powerful options.

This LED downlight has a wattage range of 22W, 28W, or 33W, providing ample lighting for different room sizes and lighting needs. Additionally, it boasts a high lumen output of 3300Lm, making it perfect for commercial, residential, and industrial lighting applications. Moreover, it has a 0-10V dimmable feature, allowing users to adjust the light intensity to their desired levels.

The LED downlight is also selectable in terms of both wattage and CCT (Correlated Color Temperature). This means that you can customize the wattage and CCT to suit your specific lighting needs. The CCT range includes 30K, 40K, or 50K, providing options for warm, neutral, or cool lighting.

The 10-inch LED downlight is an excellent replacement for traditional halogen or incandescent bulbs. It consumes less energy and lasts longer, reducing maintenance costs and electricity bills. Additionally, LED lights emit less heat, making them safer and more comfortable to use.

One of the standout features of this LED downlight is its 0-10V dimming capability. This allows for greater flexibility in lighting design, enabling users to create different lighting scenes and moods. The dimming feature also contributes to energy savings, as you can adjust the light levels based on occupancy or daylight availability.

The selectable wattage and CCT features also make this LED downlight a popular choice for a wide range of lighting applications. It is commonly used in commercial settings such as retail stores, hotels, and offices, as well as in residential settings such as living rooms, dining rooms, and kitchens. Its versatility and adaptability make it a great investment for any lighting project.

In conclusion, the 10-inch LED downlight is a high-quality, energy-efficient lighting solution that provides excellent illumination with minimal power consumption. Its 0-10V dimming feature, selectable wattage and CCT, and high lumen output make it an excellent choice for a wide range of lighting applications. Investing in this LED downlight can save you money on electricity bills while providing long-lasting, reliable lighting.
